Image Sensor |
Sensor |
Sony High Definition Color CMOS Sensor |
Display Resolution |
2.0 Megapixel |
Min. Illuminations |
0 Lux (With IR Illuminiator) |
Lens |
Lens Type |
Glass Lens |
Focal Length |
f:2.8∼ 12mm |
Aperture> |
F=1.6 |
Angle of View |
Horizontal: 40°∼105°; Diagonal: 48°∼125° |
Video |
Image Compression |
H.264 |
Image Frame Rate |
25fps maxmium, downward adjustable |
Resolution |
1080P (1920x1080), 720P (1280×720), VGA(640×480), QVGA (320×240) |
Stream |
Dual stream |
Image Adjustment |
The hue, brightness, contrast, saturation and sharpness are adjustable |
Flip Image |
Flip and mirror |
Infrared Mode |
Automatic or manual |
Pan/Tilt Angle |
Horizontal: 355°; Vertical: 90° |
Night Vision |
6pcs IR&dish;array lights, IR range up to 196 feet (60 meters) |
Audio |
Input/Output |
External 3.5mm standard interface for two‐way audio |
Audio Compression |
PCM |
Network |
Ethernet |
One 10/100Mbps RJ45 port |
Wireless Standard |
IEEE802.11b/g/n |
Data Rate |
IEEE802.11b: 11Mbps(Max.); IEEE802.11g: 54Mbps(Max.); IEEE802.11n: 150Mbps(Max.). |
Wireless Security |
WEP, WPA, WPA2 |
Network Protocol |
IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS, UPnP, RTSP |
System Requirements |
Operating System |
Microsoft Windows XP, Vista, 7, 8; Mac OS; iOS, Android |
Browsers |
Microsoft IE, Apple Safari |
Other Features |
Motion Detection |
Alert push to email, FTP and mobile app; Alarm snapshot uploaded to FTP |
Privacy Zone |
Set privacy zone manually |
User Accounts |
Three‐level user role |
Firewall |
Supports IP filtering |
Reset |
Reset button is available |
Storage |
MicroSD Card (up to 128GB) |
Power |
Power Supply |
DC12V/2.0A |
Power Consumption |
20W (Max.) |
Physical |
Dimensions (LxWxH) |
234×209×138mm (9.21"×8.23"×4.43") |
Net Weight |
1850g |
Environment |
Operating Temperature |
‐20°C~60° (‐4°F~140°F) |
Operating Humidity |
20%~85% (non‐condensing) |
Storage Temperature |
‐20°C~60° (‐4°F~140°F) |
Storage Humidity |
0%~90% (non‐condensing) |
Certification |
CE, FCC, RoHS |
