| Specification | FI9826W(Black) |
| Image Sensor | Sensor | High Definition Color CMOS Sensor |
| Display Resolution | 1280 x 960 (1.3Megapixel) |
| Min. Illumination | 0 Lux (With IR Illuminator) |
| Lens | Lens Type | Glass Lens |
| Viewing Angle | 35~70 Degree |
| focal length | f:4~9mm |
| Aperture | F1.8 |
| Audio | Input/Output | Supports two-way audio
Built-in Mic & Speaker
3.5mm audio jack for external Mic & Speaker |
| Audio Compression | PCM/G.726 |
| Video | Image Compression | H.264 |
| Image Frame Rate | 30fps maxmium, downward adjustable |
| Resolution | (1.3Megapixel)1280 x 960, 720P(1280 x 720), VGA(640 x 480), QVGA(320 x 240) |
| Stream | dual stream |
| Image adjustment | The hue, brightness, contrast, saturation, sharpness are adjustable |
| Flip image | flip and mirror |
| Infrared mode | Automatic or manual |
| Pan/Tilt Angle | Horizontal:300° & Vertical: 120° |
| Night visibility | 13pcs IR-LEDs, night vision range up to 8 metres |
| Network | Ethernet | One 10/100Mbps RJ45 port |
| Wireless Standard | IEEE802.11b/g/n |
| Data Rate | IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.). |
| Wireless Security | WEP, WPA, WPA2 |
| WPS | Supports WPS one button push wireless connection |
| Network Protocol | IP,TCP,UDP,HTTP,HTTPS,SMTP,
FTP,DHCP,DDNS,UPnP,RTSP,WPS |
| Physical | Dimension(LxWxH) | 115.8(L)*103.2(W)*118.6(H) mm |
| Gross Weight | 720g |
| Net Weight | 350g |
| Power | Power Supply | DC 5V/2.0A |
| Power Consumption | 9 Watts (Max.) |
| Environment | Operating Temp. | 0° ~ 40°C (32°F ~ 104°F) |
| Operating Humidity | 20% ~ 85% non-condensing |
| Storage Temp. | 0° ~ 40°C (32°F ~ 104°F) |
| Sstorage Humidity | 0% ~ 90% non-condensing |
| PC Requirements | Operating System | Microsoft Windows 2000/XP, Vista, 7/8;
Mac OS
iOS,Android |
| Browser | Microsoft IE6 and above version or compatible browser;
Mozilla Firefox;
Google Chrome;
Apple Safari. |
| Certificate | CE, FCC, RoHS |
| Warranty | Limited 1-year warranty |
